By Erik Sine
Maybe I should have titled it "That BrightON Halo Illumination"
Thought I would share a project where our new High-End 24 volt, .8watt BrightON II LED Modules were used.
As I've discussed before in the past. There is a difference and a gap between "Usable Light" and "Competitive Light". The BrightON II is the most efficient (Light per power) LED Module in it's class, and it is the definition of Competitive Light.
As explained here and suggested for spacing, it was chosen to use the 3" module spacer, and obviously you'll see as you scroll down the spacing could have even been much farther apart.
Using the 3" spacers or 5" on center module to module spacing of the .8 watt will give you that extra punch for Halo and Day / Night faces, and you're looking at only $2 a foot buying a single bag of modules. Important note is what you're getting for that $2 a foot. Very easily module to module spacing could have been 7" OC, and a $1.45 a foot.
The Grand Result?
No over exposure here to make the lighting more extreme than "IRL"...in real life. because I have another picture to share here of a neighboring sign that is made up of your standard front illuminated channel letters.
This is the very visual explanation of "Competitive Light".
The BrightON II Modules will give sign shops more versatility with their lighting projects, eliminating a 3 diode module & eliminating stocking more various modules with just simple spacing making the BrightON II a more universal product in your shop. The reason? Because the BrightON II meets or exceeds the Performance of most 3 diode LED Modules on the market on Maximum Efficiency of 24V. Also, the long module to module wire leads.
Could you just imagine for a second the BrightON II LED modules in the neighboring Coffee Sign at the maximum stretched module to module spacing of 7.625" or 1.57 ($1.33 a foot) modules per foot? I can!
Something is being left out here and I have to discuss what completes this High-End system?
That would be adding a France Lighting Solution LED Power supply of course
In this case the 24V France Atlas with built in LED indicator light for proper function, bringing more Quality & Dependability to the project.
The most important aspect of this job was the feedback from the client. They were VERY impressed with their sign when they drove by at night to see what their identity looked like. Their face will be your face. These are the types of results you will get with the BrightON II LED Modules.
Finished jobs will sell themselves. Happy, impressed clients will sell, and market for you...provided you not only sold them a good product but good service as well.
Come night, the mere visual can attract potential customers and a resume address can assure and close sales prospects, end results will be referral makers!
FRANCE LED POWER SUPPLIES
By Erik Sine
So, we finally did it. It's been kicked around for months, prototypes, after prototypes and locked in on a configuration that we finally liked.
As most of you know the Sign Syndicate we've been testing majority of the main stream LED's since 2008 in a unbiased benchmark comparison, tests such as "The Great White Hope....Project Tighty Whitey...Red Light District...Border Security & Blue Light Special". Over that time we've seen some characteristics that we liked, made sense, understood what will last and won't. What it means to be a High-End LED product.
We have sold the NC LED's & Axioms for a few years now, as some of our favorites from the testing (Axioms no longer). But it's been time to do our own, make it more custom and more perfect for the Sign Industry. The Brighton line is made from those in the Sign Industry.....FOR the Sign Industry.
It's BrightON, pronounced just like the city.
So what so unique about the Brighton? For starters, we wanted it to be VERY efficient. I don't know of another more bright and efficient LED module in it's class. 155 lum/W and 124lum with a 170˙ Batwing optic lens, most importantly when it comes the sign industry the important number is 63.09 Foot Candles on a sign face per Watt
The important aspects of long lasting LEDs is of course finding the "sweet spot", where it's driven just perfect for light and power. The Brighton is VERY under driven, less power, MORE light! These can be spaced out pretty far due to the optics lens, it's brighter in angles than it is straight on, or up. Under driving improves thermal performance, which extends life all while getting higher Lumens per watt. The Brighton LED is a High-End, High Performance LED module for High-End applications.
For starters off the bat we will have a 2 Diode, (no need for a 3 Diode), 4 Diode, and our Sign Cabinet model 6 Diode (SunFire). Shops won't need to stock multiple module types, the Brighton-2 is so versatile, you can use it for almost anything, just adjust the spacing. It already comes with 7" inches of wire so jumping from one row to another is easy. Space the center to center at 6" for good light, 5" center for Better Light, 4" for Best Light. They're 1.7 mods/foot and work good for shallow 2" applications depending on face type to of course much deeper.
Since these are driven so low, they don't generate a whole lot of heat, BUT, our Brighton-6 (2.8w) is Heatsinked on all Aluminum PCB for longer life.
One of the biggest complaints we have received about LEDs when it comes to large projects like large letters or cabinets is......"We have to use so MANY Power Supplies!"
A nice aspect about the Brighton is, it's a whole 24v system! Everything!
As sign companies we are redistricted by the Class II regulation of no larger than 5A per channel. So 12v is restricted to 60watts, BUT....24v is restricted to 96watts. 24v will mean more modules per power supply. You're now getting almost double the amount of modules for a project.
24V cuts that amperage that runs across the wiring and module in half! It reduces the resistance, reduces the heat and most importantly IMPROVES reliability.
I think we can all agree that LESS is BETTER, less moving parts, the less you have to worry.
This is the first part of our Brighton Line, we'll continue to improve it widening the line and of course always always staying far ahead of the curve
I'm including some rough test pics of our process and how they fair. We should have these available in the first part of Fall.
And yes, we will still stock, and continue to sell NC LED Reckless LED
Early Try Out's, various wattage and diode mfg's
FRANCE LED POWER SUPPLIES
Sign Installers, LED Video Screen, Service & Installation Technicians (Duluth, GA) Apply at Jobs@formetco.com
Formetco is a 50-year-old Duluth, Georgia based company that manufactures products sold in four divisions: Billboard Hardware, Digital LED Billboards, LED Video Scoreboards and LED Video Screens. The LED Screen business is very dynamic and fast growing. For additional information about Formetco see: http://www.formetco.com/
This is a full-time position. We are searching for a candidate that is seeking a challenging opportunity, motivated to take charge, learn, grow and desires to take on additional responsibilities. Formetco offers a comprehensive benefits package including 401K with match, health, dental, vision, long-term disability and life insurance, and paid time off in the year of hire. Formetco is a Drug-Free Work Place, and a pre-employment drug test is required.
Sign Installer, LED Video Screen, Service & Installation Technicians – We are searching for candidates to service and install large LED Screens used at high profile locations across North America. We have multiple positions open, requiring a wide range of skills ranging from steel working, crane operation, data communications, high and low voltage wiring, computer operation and networking, along with a high level of customer interpersonal communications skills. This position requires technical knowledge and good troubleshooting skills. We operate in a time sensitive environment, supporting & installing large LED Videos screens.
Experienced working with LED Electronic Signs, Scoreboards, LED Video Displays and/or experience working in the Billboard Industry is desired. Must be able to climb billboard structures, be comfortable working at heights of 100’ for extended time frames. Work can occur in a variety of weather conditions. Must have good driving record. CDL is a plus. Ability to manage and assist on-site contractors with the installation of large LED screens, from lifting and mounting, primary power installation, data communications, internet connections, sign commissioning and customer sign off. Can answer questions, manage projects, handle on site issues, communicate professionally with subcontractors, customers and manager. Must be organized, responsible person with the ability to analyze problems and communicate with manager and customers. Computer and Computer Network Knowledge Desirable. Understanding of electrical requirements for wiring general signage. Experienced with high/low voltage power distribution and data communications/networking. Good general mechanical skills and analyzing issues. Education or experience in Welding, Electrical and or Computers/Computer networking a plus. 7 Days a week operation. 50% Travel required with overnight travel and limited international travel. Have a valid passport or can obtain one. We realize that candidates will not have all the above skills. If you feel like this is something you would be interested in and have experience working at heights, climbing, overnight travel is acceptable, we encourage you to apply.
All candidates must have full authorization to work in the US without requiring current or future sponsorship.
Please list the job position you are applying for in your response. We have multiple job OPENINGS, so we need to know what position you are seeking.
Job Type: Full-time
Below are examples of typical projects
By Erik Sine
THE WHITE HORSE NC LED
Our White Horse NC LED is our Flag Ship wide angle 160˙ LED module for shallow, low profile, and general lighting projects. Shallow Lobby Signs, Channel Letters, Reverse Channel Letters, & Cabinet Lighting.
The White Horse comes in both .92 watt (186 Lumen/ft) & .72 watt (150 Lumen/ft) high powered light output LED modules, both are constant current and high grade Samsung diodes.
The White Horse is a high quality, low cost component for a lot of your Sign & Lighting applications. 100 modules per tray will give you 42 Linear feet of lighting
• 160˙ Wide Angle LED Module
• Shallow Projects, Sign Cabinet Lighting, & Channel Letters
• IP68 UL/CE
• 5 Year, 50,000 Hour Warranty
• High Brightness Light Output
• Constant Current NOT Constant Voltage
• NOT Made in CHINA
If you already like and use our Reckless NC LED Line, you'll LOVE these!
3" Depth Lobby Sign with Bright & Consistent Lighting (.92w Modules)
To Place an order Online visit our Online Shopping Cart. Lower priced Discounts to our Sign Syndicate Patron's (The Order)
For Inquiries, Questions, or to place Orders over the phone or email contact us at 858.880.1400 / email@example.com
