By Erik Sine
The BrightON-II LED .vs The Principal Qwik Mod 2 LED
So....we've been getting lot's questions on how our New High-End BrightON II LED compares to The "New" High Efficient Principal Qwik Mod 2 LED
Well, we did a quick "side by side" benchmark comparison to find out.
They have some basic similarities.
• .8 watt modules
• Both 170˙/175+ Optics
• Both have Aluminum PCB
We compared both LED modules and placed them in 24" x 4.5" x 5" channels using a standard Plexiglas MC white #7328 white acrylic face to simulate a wide channel letter stroke . Modules spaced 6" OC from one another and 3" from the channel walls.
Now to find out what the differences are...
Once we lit the channel compartments one big difference was the white appearance of each light source.
The Principal Qwik Mod produces more of a yellow white illumination on the sign face, whereas the BrightON II is more of a True White. The pictures here may not do justice as it's hard to capture Real Time and Real Life along with how your display may be calibrated.
Both BrightON II & Principals's Qwik Mod are .8w modules....The BrightON II is 24V LED module, the Qwik Mod is 12V LED module.
24V means half the current flowing through the system of a 12V system, which translates to lesser heat, lesser resistance than a 12V system. A 24V system is more reliable and a longer life system over time for the very reasons I stated.
A 24V system allows you to use a larger single watt channel PSU (96w). The BrightON LED system uses the France Lighting Solutions "True Power" LED Drivers to complete the system, "True Power" means users are able to load the PSU to 100%, where as other LED PSU's are recommended not to go beyond 85% of the rating. A full load 96W France PSU can load 120 BrightON II LED modules. France Lighting Solutions LED Drivers are the only Drivers to date that are 100% loadable.
With a 12V system a single channel 60W LED PSU is typically loaded at 85% or 51W of a 60W unit, or 63 Qwik Mods. You can load more modules on a single unit but you would have to be looking at using a 120W PSU that is a dual 60W channel unit.
Right away the biggest take away from this LED comparison in the image below is the Sign Face Surface light output results in Foot Candles using a ExTech Light Meter measuring the High's and Low's in the 7" x 4" rectangle area of the acrylic face.
The BrightON II has a Foot Candle Average of 209 versus Principal's Qwik Mod coming in lower at 171 Foot Candles.
A HUGE difference which will play big in lighting and in life is how the current is driving across each module. The BrightON II is of course Constant Current, NOT Constant Voltage. The Qwik Mod is Constant Voltage.
The quickest, simplest explanation and differences is this. On a Constant Current system, each module has a current regulator chip which means each module is current regulated, and protected not to overdrive and create more heat and run hotter. The first module on a Constant Current string is equally as bright as the last module on a string....the result is consistent lighting. If you've ever paid attention to the light testing we have been doing on The Sign Syndicate since 2009', you would know that the best and lowest light degradation or Lumen Maintenance results always came from CC LED systems, Constant Voltage or "Eco" Modules not so much.
In a CV System you better hope your LED PSU is not driving above the intended voltage of 12 volts. A slight increase in a fraction of a volt... say...12.2V can kill a LED system fast depending on the makeup of the Modules. When we did our Light Testing "The Great White Hope" we had a incident where a LED PSU operating at 12.25 was used on a Permlight "El Plato Module which was CV and in under 30 days the original output dropped 30%. We had to kick out the PSU and start over with another string of EL Plato's using a manual adjustable LED PSU to assure not to go above 12V.
On a typical CV System on long runs the first module will be brighter than the last module on the same string, inconsistent lighting, with a not well regulated LED PSU CV LED will tend to run hotter and brighter in some areas causing a shorter life. The system is solely dependent on the module resistors for protection.
Constant Voltage = Lesser LED life over time
Constant Current = Longer LED life over time
Below.....you can take what you want from this part...
We used equal underexposed shots from both LED light sources from a Canon SLR Camera instead of Real Time to show our audience where the optics is transferring light
We used a lighting angle chart that we created, made up of 1" grids just to help in displaying where the optics and throwing light. Both Module have wide angle optics, I would just say that the Brighton II throws more light towards the edge of the chart and a little higher up the middle.
What It All Means
In closing, the biggest differences that can be taken away from this benchmark comparison and what separates the BrightON II are a couple of big factors.
• The BrightON 24 volt system which has half the amperage, heat, & resistance than the 12 volt Principal Qwik Mod LED system. You're also able to load more LED modules on a 24V system than a 12 volt system
• If you're looking for a more "Purer" white light source, better bin, then the BrightON LED Module family is for you.
• More light for less power on the sign surface....better chip efficiency... that was just displayed and shown in Foot Candles....BrightON II 209 FC over Principal Qwik Mod 2 171 FC
• Probably the single most important factor? The BrightON LED Family is Constant Current rather than a lower costing system that uses unregulated current in Constant Voltage. What that means for user is....Longer Consistent Life Over Time
The New BrightON LED
The previous High-End BrightON LED version has had a lot of success since the launch. What is new? Only some miner changes were made to make a already superior LED module even better. Same high efficient chip, improved 6500 Kelvin, different optics.
Not that we needed it but, the BrightON is, and has always been underdriven but....we changed from a Fiberglas PCB Board to Aluminum. Aluminum provides better thermal cooling, but again, it wasn't needed....it's just nice to brag about it and say we have Aluminum.
The New BrightON LED Family will in stock by early May 2021.
The BrightON LEDs can now be purchased from our our online store HERE, or you can order over the phone (858) 880-1400 | email@example.com
It's been some time since we've stocked Toggle Switches so....we're now stocking Toggle Switches.
We just brought in a bunch of switches after numerous requests and thought we would also throw a special together for this very announcement.
Box of 25 France Lighting Solutions Toggle Switches for $103.75 or $4.15 each and FREE SHIPPING anywhere in the Continental U.S. Call in or Email for special Flat Rate for Hawaii & Alaska
FRANCE LIGHTING SOLUTIONS
UL879 Recognized Component Wet, Damp, & Dry Location 20 Amp - 120-277 VAC - 2HP 12" Lead Wires Silicone Boot On-Off Faceplate 1/2" Panel Opening Per UL48 - 20 Amp VAC Rated Switches are Limited to a Total Transformer Load of 10 Amps
Members can take advantage of this special and purchase using our Online Shopping Cart, or you're more than welcome to email us at firstname.lastname@example.org or phone in at (858) 880-1400
By Erik Sine
Introducing our new Sign Syndicate BrightON II LED module. It's the newest all around LED Module for your Channel Letter, Sign Cabinet, and Linear Lighting needs.
BrightON, pronounced like the city
Just like our BrightON Sunfire LED Module, the II is just as unique.
The BrightON II rids the need for shops having to stock a 2 and 3 Diode Module for different size lettering. The BrightON II meets or exceeds the performance of most 3 Diode LED Modules on the market with our Maximum performance efficiency at 24V
The BrightON II LEDs are under driven for Improved Thermal Performance
Through all the various testing we have done here on the Sign Syndicate when it came to Neon or LED illuminated channel letter testing as well as feedback from customers who purchase our NC Reckless LED Line. When it comes to illuminating signs, there is a divide between, Very Bright / Competitive Lighting / Usable Light.
Competitive Light begins around the 170+ Foot Candles on a sign face surface, Brighter Light 190 FC+ and above. Anything under 150 Foot candles is just Usable, or Acceptable light.
To date, our BrightON II is the most efficient LED module in it's class in light output per power given.
Below are some our biggest competitors that we all see from cover to cover advertised in monthly paid brochure trade magazines. For our own purposes we've limited it to two, because.....they have been the most marketed and we can't help but turn a corner in this industry and there they are, an ad to tell us how great they are. Also listed, we have our NC Reckless LED Line.
The test channel are 4" x 2'. Same as our Great White Hope II Test. 4" tall because our industry standard has usually been, anything (stroke) beyond 4" will require another stroke of Neon, or LED Row.
The Hanley PE-4 is a 4 diode module with 3 mods, & the Hanley PE-2 is a 2 diode module with 4 mods in the channel
Principal Heavy Weight is 3 diodes per module, and 4 modules in the channel
NC Reckless-2 is a 2 diode module with 6 mods, and Reckless-3 is a 3 diode module with 4 mods in the channel
BrightON II is the same spacing and module count as the Hanley PE-2, or 2 diode mod, 4 mods in the channel
From the sign surface light output measured in Foot Candles, combined with the Foot Candles per watt, the BrightON II has exceeded our competition with like modules in it's class. Even some modules with higher output rating (1.32w, .92w) module and a higher mod count in the same measured channel.
In other words with the BrighON II, you're getting more light with less modules, more light at a lower project cost, and more light at a lower cost of operation.
That's efficiency in a lot more ways than one!!!
A single bag of BrightON II LED modules is composed of 80 modules.
Fully stretched Module to Module on a string gives you 7.625" on center, 5.5" of wire between module, that's 50.83 Linear feet of light, or 1.57 modules per foot.
We purposely gave the BrightON II just like the SunFire an extra wire length. The extra wire length was configured to give extra space for not only for changing your lighting needs, but also to save labor on single stroke LED layouts for going in and back out of letter layout for "Bars, Extensions, & Serifs" such as E's and F's among others without having to make a splice. The extra wire length will also allow you enough wire to jump and make a 5" row to row. One of the bigger feedback's we received was a lack of wire space. With our High Efficiency diodes combined with 175˙ Optics, our modules don't need to be spaced so close together for light uniformity.
All of our orders will be sent with three convenient module spacers for laying out your modules faster rather than by naked eye, or tape measuring out if you need.
The three spacers serve a purpose.
The 175˙ Deg Optics gives you a unique ability to spread the High-End Super Efficient Light of the BrightON II LED Module. Fully stretched you already have above competitive light as listed above in a 5" channel.
- Fully Stretched is 7.625" Module to Module OC, giving you slightly lower lighting levels than listed down below. This is for your typical everyday channel letters you can economize and still have above competitive light. (50.83 Liner feet of light, $1.33 a foot)
- The first spacer is 5" long for a 7" Module to Module OC, giving you 192 FC on a 5" deep sign face surface, this is for your typical everyday channel letters. (46.66 Linear feet of light, $1.45 a foot)
- The second spacer is 4" long for a 6" Module to Module OC, giving you 200 FC on a 5" deep sign face surface, this is for your competitive build channel letters that might require more light (Freeway Visible) and for Halo Lighting (40 Liner feet of light, $1.70 a foot)
- The third spacer is 3" long for a 5"Module to Module OC, giving you 235 FC on a 5" deep sign face surface, this is for your specialty channel letters that may have Day/Night faces that you want to look White White at Night, and NOT a murky dirty Gray, or again for Halo Lettering that need that PUNCH! (33.33 Linear feet of light, $2.04 a foot)
CHANNEL COMPARISON (Our Old High End vs Our New High End)
Our Highly Light Efficient .8w BrightON II LED Module (175 Deg) vs NC's .9w LED(140 Deg) HLC LED Module Series with Samsung chips. You see these Module casings used by many GOQ, to just about any Korean or Chinese Based Module.
There are a couple of factors that can make a LED module Light Efficient, optics and of course the chip. Our BrightON series has both, bigger part rests on the chip. I know this because early on development I tried to integrate the Samsung chip to our module casings, and well...with the amount of light we got from power driven....it got it's ass kicked by the one we chose. You can't just throw in any or some decent chip in a cool looking module with cool optics and expect it to go perform well.....that's like throwing in a Yugo motor in a Ferrari body and having great expectations
Here is a what's in a 4" x 2' Channel with standard 5" depth
NC has 6 LED modules. 6 x .9w = 5.52 watts and achieving 203 Foot candles of light on a #7328 sign surface, and doing it at 35 Foot candles per watt
Our High-End BrightON II has only 4 modules. 4 x .8w = 3.36 watts and achieving 214 Foot candles of light on a #7328 sign surface, and doing it at 63.09 Foot candles per watt.
We always hear marketing words of "Energy Efficient". What is Energy Efficient? It's comparing two equal sources and when one is doing it for equal or greater with a lesser cost of operation...that is "efficient"
We're comparing one compartment with six .9w modules against another with only 4 modules that are only .8w each. You would think the bigger wattage LED should win right?
Don't get me wrong about NC. In the LED Module world, NC LED Kicks the crap out of a lot LED Manufacturers, ALOT. I've shown and illustrated that many times here on the Sign Syndicate. But....Every Dog has his day... Wait, let me walk some of this back. Not all NC LED modules are the same as I've explained in the past, only our special configured Reckless was the one that really kicked ass.
LIGHT SPLASH RADIANCE
Both Modules are 3" from the wall surface.
Check out that angle and splash radiance of both.
You can't even identify the horizontal measuring tape with the high powered NC LED Module, look at the small light output range radiating from the NC LED
Now the BrightON II......
Look at how much light is splashed on the surface each one of the modules is mounted to!
In the end,....More light with lesser modules.
Efficient Light, Efficient Cost, and it's doing it at a much lesser cost of operation.
Beside the important aspect that the BrightON II LEDs are 24 volt modules, most importantly they are Constant Current....NOT Constant Voltage. What is that?
Constant Current Systems mean, every LED module is integrated with a Current Driver (Not just resistors) for protection keeping the current the same one each module from the first to the last module on a string. What does this do?
In short, Constant Voltage LED Systems have no regulation, only resistors for protection. On a Constant Current System the brightness of the first LED on a long string is just as bright as the last LED on the same string, unlike CV where the first LED will be brighter than the last. The first LED on a CV system is taking a bigger hit from the power supply than the last.
Protection from LED Power Supplies. Each LED PS has a different DC Output, it can range from 12v to 12.25v. Each additional traction of a volt can kill a CV LED system because it's NOT regulated and it's taking a bigger hit. As mentioned on the Sign Syndicate before in the past, while installing a set of CV Permlight LEDs for our Neon & LED Bench Mark Test (The Great White Hope) where all strings were set on a dedicated PS, it wasn't noticed that a manually adjustable LED Power Supply was previously set for 12.20 volts not 12.0 volts from previous benchmark testing, and within 30 days the LED string had degraded 30%. This is what a fraction of a volt can do to various LED product lines based on how they are developed
With CC LEDs, the output of the PS is regulated across the LED modules, more power won't hurt it.
When you hear such words affiliated to LED product lines such as "Eco, or value line" it means Constant Voltage
Constant Current LEDs have longer life spans because they are protected. We've always been very big here on the Sign Syndicate about Constant Current systems
24 VOLT SYSTEM
The Complete BrightON Line is 24v, NOT 12v, there is a clear advantage for this.
First and most importantly, this 24v system operation halves the amperage running through the Wiring and Modules reducing the heat, resistance, & improving reliability You'll also have more voltage headroom for longer runs.
With a 24v system you can load more on a power supply. With a 12v system you are limited to a 60W power supply channel with U.L. regulations, with a 24v you are forded 96W. That's a lot more modules per channel! Less cost, less labor, less moving parts so to speak.
24 VOLT POWER SUPPLIES
We recommend using our choice LED Power Supply for our system, and that is non other than France Lighting Solutions.
France isn't just some brand we so happen to stock. We went out of our way and asked them (truth be told....I got on my hands and knees and begged) if we could compliment our High-End BrightON Line with their High-End LED Power Supplies.
Here is the reason why for my pride swallowing experience.
With your typical LED Power Supply (Insert name here), you'll be loading (depending on brand) it to 80%-85% of your full 96W channel, or 77 watts to 81 watts of LEDs, leaving room for voltage loss etc to keep from stressing your power supply. With our Brighton II LEDs, that's 96 to 101 LED Modules.
We want to offer nothing but the best.
With France Lighting Solutions...and if you've been in this electric sign industry long enough to know when it comes to their Neon or LED Power Supplies, you're getting not only quality, but longevity, & dependability.
With the France Atlas & Eco Series that we stock to compliment our system, you are getting the only, ONLY "True Power" LED Power Supply in the industry
True Power means that you have the ability to load their power supplies to Full Load.
That's the way they were engineered, that's the way they are made, and that is what you're getting alongside our LEDs to give you a complete High-End System for all your Sign & Lighting Projects
The Atlas series even has a LED indicator light to tell if you're loading too many LEDs on the power supply.
With a France "True Power" LED Power Supply you can load 120 BrightON II LED modules, that's almost a 24 module difference over using another brand LED power supply. That 24 more additional modules can make the difference in NOT having to add another or multiple LED power supplies for a single sign or project. You will be saving cost and labor from having to add another or multiple LED power supplies for a Sign or Cabinet.
We will be stocking 24V France 96W, 60W, and 30W LED Power Supplies http://www.thesignsyndicate.com/forums/index.php?/store/category/22-led-power-supplies/
- High-End 24V LED Module System
- .8 watts per module
- 155 lum/W Efficiency
- 175 Degree High Efficiency Uniformity Optics
- Constant Current, NOT Constant Voltage
- 5 Year, 50,000 Hour Warranty
- 6500K Temperature Light
- U.L. File E520387
- 80 Modules Per Bag (Fully Stretched 50.83', 1.57 Mods/Ft)
- Load 120 Modules on a single France 96W LED PS
For Place Orders by phone, by email, or for inquires we can be contacted at (858) 880-1400 - email@example.com or use our online shopping cart.
