By Erik Sine
So, we finally did it. It's been kicked around for months, prototypes, after prototypes and locked in on a configuration that we finally liked.
As most of you know the Sign Syndicate we've been testing majority of the main stream LED's since 2008 in a unbiased benchmark comparison, tests such as "The Great White Hope....Project Tighty Whitey...Red Light District...Border Security & Blue Light Special". Over that time we've seen some characteristics that we liked, made sense, understood what will last and won't. What it means to be a High-End LED product.
We have sold the NC LED's & Axioms for a few years now, as some of our favorites from the testing (Axioms no longer). But it's been time to do our own, make it more custom and more perfect for the Sign Industry. The Brighton line is made from those in the Sign Industry.....FOR the Sign Industry.
It's BrightON, pronounced just like the city.
So what so unique about the Brighton? For starters, we wanted it to be VERY efficient. I don't know of another more bright and efficient LED module in it's class. 155 lum/W and 124lum with a 170˙ Batwing optic lens, most importantly when it comes the sign industry the important number is 63.09 Foot Candles on a sign face per Watt
The important aspects of long lasting LEDs is of course finding the "sweet spot", where it's driven just perfect for light and power. The Brighton is VERY under driven, less power, MORE light! These can be spaced out pretty far due to the optics lens, it's brighter in angles than it is straight on, or up. Under driving improves thermal performance, which extends life all while getting higher Lumens per watt. The Brighton LED is a High-End, High Performance LED module for High-End applications.
For starters off the bat we will have a 2 Diode, (no need for a 3 Diode), 4 Diode, and our Sign Cabinet model 6 Diode (SunFire). Shops won't need to stock multiple module types, the Brighton-2 is so versatile, you can use it for almost anything, just adjust the spacing. It already comes with 7" inches of wire so jumping from one row to another is easy. Space the center to center at 6" for good light, 5" center for Better Light, 4" for Best Light. They're 1.7 mods/foot and work good for shallow 2" applications depending on face type to of course much deeper.
Since these are driven so low, they don't generate a whole lot of heat, BUT, our Brighton-6 (2.8w) is Heatsinked on all Aluminum PCB for longer life.
One of the biggest complaints we have received about LEDs when it comes to large projects like large letters or cabinets is......"We have to use so MANY Power Supplies!"
A nice aspect about the Brighton is, it's a whole 24v system! Everything!
As sign companies we are redistricted by the Class II regulation of no larger than 5A per channel. So 12v is restricted to 60watts, BUT....24v is restricted to 96watts. 24v will mean more modules per power supply. You're now getting almost double the amount of modules for a project.
24V cuts that amperage that runs across the wiring and module in half! It reduces the resistance, reduces the heat and most importantly IMPROVES reliability.
I think we can all agree that LESS is BETTER, less moving parts, the less you have to worry.
This is the first part of our Brighton Line, we'll continue to improve it widening the line and of course always always staying far ahead of the curve
I'm including some rough test pics of our process and how they fair. We should have these available in the first part of Fall.
And yes, we will still stock, and continue to sell NC LED Reckless LED
Early Try Out's, various wattage and diode mfg's
Well established sign company seeking a neon tube bender open to working throughout the sign trade. Our clients are accustomed to an extreme level of service and high quality products delivered in a timely manner by highly professional staff.
Requires either tube bending experience or recent tube bending school attendance.
General knowledge of the sign trade helpful
Good customer relations
Sign Installers, LED Video Screen, Service & Installation Technicians (Duluth, GA) Apply at Jobs@formetco.com
Formetco is a 50-year-old Duluth, Georgia based company that manufactures products sold in four divisions: Billboard Hardware, Digital LED Billboards, LED Video Scoreboards and LED Video Screens. The LED Screen business is very dynamic and fast growing. For additional information about Formetco see: http://www.formetco.com/
This is a full-time position. We are searching for a candidate that is seeking a challenging opportunity, motivated to take charge, learn, grow and desires to take on additional responsibilities. Formetco offers a comprehensive benefits package including 401K with match, health, dental, vision, long-term disability and life insurance, and paid time off in the year of hire. Formetco is a Drug-Free Work Place, and a pre-employment drug test is required.
Sign Installer, LED Video Screen, Service & Installation Technicians – We are searching for candidates to service and install large LED Screens used at high profile locations across North America. We have multiple positions open, requiring a wide range of skills ranging from steel working, crane operation, data communications, high and low voltage wiring, computer operation and networking, along with a high level of customer interpersonal communications skills. This position requires technical knowledge and good troubleshooting skills. We operate in a time sensitive environment, supporting & installing large LED Videos screens.
Experienced working with LED Electronic Signs, Scoreboards, LED Video Displays and/or experience working in the Billboard Industry is desired. Must be able to climb billboard structures, be comfortable working at heights of 100’ for extended time frames. Work can occur in a variety of weather conditions. Must have good driving record. CDL is a plus. Ability to manage and assist on-site contractors with the installation of large LED screens, from lifting and mounting, primary power installation, data communications, internet connections, sign commissioning and customer sign off. Can answer questions, manage projects, handle on site issues, communicate professionally with subcontractors, customers and manager. Must be organized, responsible person with the ability to analyze problems and communicate with manager and customers. Computer and Computer Network Knowledge Desirable. Understanding of electrical requirements for wiring general signage. Experienced with high/low voltage power distribution and data communications/networking. Good general mechanical skills and analyzing issues. Education or experience in Welding, Electrical and or Computers/Computer networking a plus. 7 Days a week operation. 50% Travel required with overnight travel and limited international travel. Have a valid passport or can obtain one. We realize that candidates will not have all the above skills. If you feel like this is something you would be interested in and have experience working at heights, climbing, overnight travel is acceptable, we encourage you to apply.
All candidates must have full authorization to work in the US without requiring current or future sponsorship.
Please list the job position you are applying for in your response. We have multiple job OPENINGS, so we need to know what position you are seeking.
Job Type: Full-time
Below are examples of typical projects
By Erik Sine
PK, or Neon P-K Housings are harder and harder to find these days with no major Neon Manufacturer still producing the Metal Shroud portion of a PK Housing. Westrim?? Nope....Transco? Nope....Allanson? Nope...
In fact, it's been nearly impossible to find New complete PK Housings.
The only way in the last couple of years if you had a Neon Project for a client has been to find existing stock from a sign company that has had some just sitting on a old dusty shelf somewhere, or possibly a sign supplier who didn't even know they had any, and with LEDs flooding the market it's doubtful a supplier rep even knows what they are/were, and that dusty case they do have with all those strange metal & glass components was possibly spare parts for some old delivery truck their company use to have from the 90's???
Think of how many have just been straight thrown out in the garbage
Well, not every Neon wall project calls for #200, #300 Housings, the difficult Masters Technologies Boots and Sleeving System. If you want a Neon attached to on a wall for a clean look & without a raceway, YES...it IS still possible!!!
We've been sitting on these for some time, sorry for the late public announcement
Store Link of Neon Housings
Call or Email us for questions or orders!! orders@thesignsyndicate (858) 880-1400
I am trying to replace an obsolete neon transformer on a bar light and cannot seem to find anyone who can confirm what modern transformer will work as the proper replacement. That's why I came here to the experts!
I've attached a photo of the old indoor gas tube transformer.
I believe it says it's an Actown Model No. FG 3851.
PRIM 120 Volts 60 Hz 270VA
SEC 9,000 Volts 30 MA
Secondary Mid-Point Grounded
I believe Actown was bought by Franceformer years ago.
Can anyone offer any insight on what a solid replacement transformer for a bar neon would be?
Any info. anyone can provide would be greatly appreciated.
