By Erik Sine
We always strive on information here on The Sign Syndicate. Everything from National Sign & Subcontractor Reviews on "payments & relationships" to "How To"...better ways to build sign systems and projects based on longevity & reliability .
So, we're very, VERY excited (I want to say "Super Excited" but it's so over used) to announce our whole new upcoming Sign Syndicate 24V BrightON (Pronounced like the city) LED system just got even better. Better because we will be complimenting our High Powered, High Efficient LED Module system with France Lighting Solutions 24V LED Drivers.
I have talked about France products quite a bit here over the years, mainly when it comes to Neon. The quality, that high bar of standards, most importantly....the "Reliability".
From Neon to LED Power Supplies, expect nothing different, nothing less from France Lighting Solutions. But, actually here is something different about their LED Drivers, something "Cool".
The France LED Drivers are the ONLY drivers that are "True Power".
What is "True Power"?
In short......It means they are the ONLY LED driver in the electric sign industry that you can load to the MAX. Not the typical load to 80% - 85% leaving room for voltage loss, wiring etc. Load to MAX.....if you want.
We are just a month away from releasing the Sign Industries most light/power efficient LED Module on the market that will definitely put it's mark on this industry. You'll be able to get the most light for very little cost of operation. Get more for less.....be on a 24V system which give sign shops the unique ability to load more modules on a single power supply. A 24V system reduces the heat, resistance, and amperage compared to a 12V system, you'll have more voltage headroom for longer wiring lengths.
With a 24V system you're not restricted to 60 Watts per channel, BUT 96 Watts.....that's almost double!
Complimenting our new LED System with France's "True Power" LED Drivers and adding them to your electric sign projects you'll be able to load 120 .8w BrightON 2 LED modules. That's 76.25 Linear feet of high powered LED modules for anything from everyday channel letters to cabinet & perimeter lighting.
For our High Powered Sign Cabinet Lighting module, BrightON SunFire (3w), that France "True Power" LED Driver will give you 40 to 50 Linear Feet for your Sign Cabinets
France Lighting Solutions DRV24100E Dry & Damp Location
France Lighting Solutions DRV24100A Dry, Damp & WET Location
Those Sign Face Foot Candle numbers!!! Look at the "Foot Candles Per Watt" (Higher is better)
Our complete High Powered High Efficient BrightON LED System with France Lighting Solutions, that's DOUBLE reliability!!!
France "True Power" 24V LED Power Supplies
By Erik Sine
So, we finally did it. It's been kicked around for months, prototypes, after prototypes and locked in on a configuration that we finally liked.
As most of you know the Sign Syndicate we've been testing majority of the main stream LED's since 2008 in a unbiased benchmark comparison, tests such as "The Great White Hope....Project Tighty Whitey...Red Light District...Border Security & Blue Light Special". Over that time we've seen some characteristics that we liked, made sense, understood what will last and won't. What it means to be a High-End LED product.
We have sold the NC LED's & Axioms for a few years now, as some of our favorites from the testing (Axioms no longer). But it's been time to do our own, make it more custom and more perfect for the Sign Industry. The Brighton line is made from those in the Sign Industry.....FOR the Sign Industry.
It's BrightON, pronounced just like the city.
So what so unique about the Brighton? For starters, we wanted it to be VERY efficient. I don't know of another more bright and efficient LED module in it's class. 155 lum/W and 124lum with a 170˙ Batwing optic lens, most importantly when it comes the sign industry the important number is 63.09 Foot Candles on a sign face per Watt
The important aspects of long lasting LEDs is of course finding the "sweet spot", where it's driven just perfect for light and power. The Brighton is VERY under driven, less power, MORE light! These can be spaced out pretty far due to the optics lens, it's brighter in angles than it is straight on, or up. Under driving improves thermal performance, which extends life all while getting higher Lumens per watt. The Brighton LED is a High-End, High Performance LED module for High-End applications.
For starters off the bat we will have a 2 Diode, (no need for a 3 Diode), 4 Diode, and our Sign Cabinet model 6 Diode (SunFire). Shops won't need to stock multiple module types, the Brighton-2 is so versatile, you can use it for almost anything, just adjust the spacing. It already comes with 7" inches of wire so jumping from one row to another is easy. Space the center to center at 6" for good light, 5" center for Better Light, 4" for Best Light. They're 1.7 mods/foot and work good for shallow 2" applications depending on face type to of course much deeper.
Since these are driven so low, they don't generate a whole lot of heat, BUT, our Brighton-6 (2.8w) is Heatsinked on all Aluminum PCB for longer life.
One of the biggest complaints we have received about LEDs when it comes to large projects like large letters or cabinets is......"We have to use so MANY Power Supplies!"
A nice aspect about the Brighton is, it's a whole 24v system! Everything!
As sign companies we are redistricted by the Class II regulation of no larger than 5A per channel. So 12v is restricted to 60watts, BUT....24v is restricted to 96watts. 24v will mean more modules per power supply. You're now getting almost double the amount of modules for a project.
24V cuts that amperage that runs across the wiring and module in half! It reduces the resistance, reduces the heat and most importantly IMPROVES reliability.
I think we can all agree that LESS is BETTER, less moving parts, the less you have to worry.
This is the first part of our Brighton Line, we'll continue to improve it widening the line and of course always always staying far ahead of the curve
I'm including some rough test pics of our process and how they fair. We should have these available in the first part of Fall.
And yes, we will still stock, and continue to sell NC LED Reckless LED
Early Try Out's, various wattage and diode mfg's
FRANCE LED POWER SUPPLIES
By Erik Sine
I haven't posted any jobs lately and I need to play catch up.
So I'll start with our latest projects and work myself backwards
As we've discussed so many times on the Sign Syndicate. There is a time to retrofit, and a time not too. Neon and Fluorescent lamps/systems should not in most cases be retrofitted to LEDs unless accessibility calls for it. Otherwise, it doesn't make financial sense for the consumer to do so, or....just so a shop can make a project sale on BS energy efficiency numbers and mythical saving $$$$
So here are some retrofit jobs that make REAL sense.
Here's a chain of Studio's that I've been doing since the early 2000's.
This particular sign is only partially mine, everything from the Logo and red letters.
This was the first job I did for them leading up to fabricating all new signs for their locations. The white is from the previous location and Neon has been in it's original form since the late 90's, and it's 6500K Snow White. The logo is 15mm Tri-phosphor, Elite 65D I believe. The Logo and Red was done in 2008. It's very hard to tell because red and white is hard to capture and a cell phone cam does no justice but the White lettering is dimmer than illustrated and is about 50% of it's original light output.
Not bad for 20+ plus year old lamps!!
So the owner called up and wanted a revamp. Had I been the average shop you bet the immediate response would have been LED! SAVINGS!!!!! BULLSHIT! BULLSHIT!
We're logical over here in SoCal, a land where 50¢ modules would have replaced the Lamp Art.
The logical choice, and more economical choice for the consumer?
Going from a single halo phosphate 6500K Snow White Neon lamp to a Tri-Phosphor EGL Designer 7100 Series Lamps.
When we moved and installed (2008) this sign we did so with Tecnolux Silicone GTO and Caps. All that was needed for this retrofit was new lamps, and leaving the awesome silicone GTO and transformers in place!
Now, I owe you a night shot, the iphone pic I took was garbage, so I'll update that soon. But the Logo and White letters match up well, and even with the old faces, the sign illuminates like a new sign at night.
Forgot to mention, the white faces are also from the 90's and they've held up quite well, the Trim Cap is Plasco, also held up quite well for 20+ years old. During the day, the ace look good, so no need to replace.
So a new client...
They called, they were moving and wanted to know if they needed a new sign or whether to fabricate a whole new on because the current was lit up like crap. Had hot spots, dim a places, and just crazy outages in sections of letters.
It would have been better had I taken night pics, BUT...I didn't know I would be posting and writing about it here so
Had this been some other shop, I'm sure the nightmare would have continued
Yes, two different LED manufacturers in the same sign Woohoo, the electric sign industry in it's finest form right here! It made me SO proud!
If you're familiar with Gaverieli Plastics, I need say no more, let alone Chinese JS LED's....well, their both China and their both crap.
They don't last, they fail, they cause companies problems with having to go back and replace and most importantly...They cost the consumer, YOUR client.
The second sign which they had, made at a different time and by another company was US LED, also garbage. Illumination was just as bad. Sorry, didn't get pics of that sign because again, it wasn't my plan to make a post here
If this wonderful, thoughtful sign package doesn't make you cry, I don't know what will.
The original plastic was green vinyl over white acrylic and in such a short time this sign was beat, and probably why they called a new contractor for the work for their sign move.
Well, a new sign made no sense.
They were just moving a few suites over and they weren't going to get a larger sign so the original would do. New faces with 3M Lime Green over White acrylic.
The most important aspect of this Sign....
NC Reckless-3 LEDs. Top Tier Samsung Diodes running on a Constant Current system...NOT Constant Voltage. 1.2 watt modules. Most important detail about our NC Reckless LEDs? Their made in Korea NOT CHINA!!!
Check out that crazy light meter reading! That's almost 300 surface Foot Candles, which is about the equivalent light output to a 13mm Tri-phosphor white Neon Lamp behind white acrylic.
If that is not simply utterly gross and disgusting, and you're not just sickened by that number, you have no stomach
These Reckless-3 LEDs will NOT be powered up by their low budget power supplies but rather our Union LED Power Supplies made in KOREA, not CHINA!!!
It's usually best to retrofit out with what was already in a sign, and not change one light source to another. It's makes more financial sense in MOST cases, not all, but most.
By Erik Sine
NC LED Get's Better and Better $69.99!
Introducing the NEW NC LED "White Horse" Wide Angle Constant Current Series.
The White Horse CC series is a diffused lens LED module to better spread the light for shallow electric sign applications like 2" push thru architectural cabinets and channel letters available in 2, 3, and 4 chip diode configurations.
The module is the same as the NC Reckless series discussed here
• 5 Year 50,000 Hour Warranty
• 160˙ Wide Angle Diffused Lens
• Constant Current, NOT Constant Voltage
• High Brightness LED Module
• Made in Korea NOT made in CHINA!!!
• ONLY $69.99 per 100 WH2 Modules 42' Linear Feet
NC LED DOWNLOADABLE SPEC SHEETS: NC-SS-0416-Brochure.pdf
This White Horse series is a 160˙ degree light disbursement LED module and is the same chip for brightness as our Reckless series but because of the diffused lens the light is spread better for even lighting for shallow based sign faces for channel letters, dimensional letters or cabinets.
As you know diffused wide angle modules won't be as effective for standard channel letter illumination as the Reckless series but great for shallow depth channel letters BUT, with the sick brightness of the NC Reckless LED series you can probably use this for both applications.
Two great modules with the same makeup mixed with high Korean standards, with these standards think high, over engineered Japanese standards.... lastly..........say it with me.......NOT made in CHINA!!!
For orders use our online shopping cart or to contact us call or email
(858) 880-1400 / email@example.com
